15 SYSTEM DESIGN

The processor supports many system design options. The options imple-
mented in a system are influenced by cost, performance, and system
requirements. This chapter provides the following system design
information:
• "Pin Descriptions" on page 15-2
• "Phase-Locked Loop Startup" on page 15-13
• "Conditioning Input Signals" on page 15-14
• "Designing for High Frequency Operation" on page 15-15
• "Booting" on page 15-19
Other chapters also discuss system design issues. Some other locations for
system design information include:
• "SPORT Operation Modes" on page 9-9
• "SPI General Operations" on page 10-7
By following the guidelines described in this chapter, you can ease the
design process for your ADSP-2126x product. Development and testing
of your application code and hardware can begin without debugging the
debug port.
