Table 479. Gtmdi_Aru_Wpc2 Field Descriptions - STMicroelectronics SPC572L series Reference Manual

GTM Development Interface (GTMDI)
Register index: 51
31 30
R 0
WTSEL1
W
RESET: 0 0
15 14
R 0
WTSEL2
W
RESET: 0 0
Table 479
Field
Watchpoint Trigger Output Selection 1. The WTSEL1[2:0] field selects among 8 available
watchpoint triggers which one is connected to the ARU Debugging Channel 0. Other modules can
selected the same WTSEL1 value, in this case the result selection is an OR of all selected sources.
000 SHARED_WPT[0]
001 SHARED_WPT[1]
30–28
010 SHARED_WPT[2]
WTSEL1
011 SHARED_WPT[3]
100 SHARED_WPT[4]
101 SHARED_WPT[5]
110 SHARED_WPT[6]
111 SHARED_WPT[7]
Start/Stop input signal selection 1. Selects the Start/Stop input that is used to control the watchpoint
trace messages for ARU Debugging Channel 0. These signals are actually a pair of signals.
21–20
00 SHARED_WPT_ST[0]
STSEL1 01 SHARED_WPT_ST[1]
10 SHARED_WPT_ST[2]
11 SHARED_WPT_ST[3]
Watchpoint Trigger Enable 1. The TEN1 field controls if a watchpoint external trigger is issued by
17 the ARU debugging Channel 0.
TEN1 0 Disable Trigger Generation
1 Enable Trigger Generation
Start/Stop Enable 1. The SEN1 bit field enable the ARU Debugging Channel 0 to consider the
Start/Stop inputs for watchpoint trace message generation. If this bit is cleared, the messages are
16
controlled only by JTAG writes to the WMC1 field in the GTMDI_ARU_WPC1 register.
SEN1
0 Disable trace control from Start/Stop inputs
1 Enable trace control from Start/Stop inputs
