STMicroelectronics SPC572L series Reference Manual page 1375

RM0400
Field
12 Reserved for future use. Reads returns zeros.
Number of Data Nibbles supported in Channel 3
13:15
NIBBCH3 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
16 Reserved for future use. Reads returns zeros.
Number of Data Nibbles supported in Channel 4
17:19
NICCH4 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
20 Reserved for future use. Reads returns zeros.
Number of Data Nibbles supported in Channel 5
21:23
NIBBCH5 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
24 Reserved for future use. Reads returns zeros.
Number of Data Nibbles supported in Channel 6
25:27
NIBBCH6 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
28 Reserved for future use. Reads returns zeros.
Number of Data Nibbles supported in Channel 7
29:31
NIBBCH7 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
Table 795. DATA_CTRL1 field descriptions(Continued)
DocID027809 Rev 4
Description
SENT Receiver (SRX)
1375/2058
