Rmon Rx 128 To 255 Byte Packets (Rmon_R_P128To255) - STMicroelectronics SPC572L series Reference Manual

Fast Ethernet Controller (FEC)
48.4.66

RMON Rx 128 to 255 byte packets (RMON_R_P128TO255)

Offset: 2B0h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 755. RMON Rx 128 to 255 byte packets (RMON_R_P128TO255)
Field
RMON_R_P128TO255 RMON Rx 128 to 255 byte packets
48.4.67 RMON Rx 256 to 511 byte packets (RMON_R_P256TO511)
Offset: 2B4h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 756. RMON Rx 256 to 511 byte packets (RMON_R_P256TO511)
Field
RMON_R_P256TO511 RMON Rx 256 to 511 byte packets
48.4.68 RMON Rx 512 to 1023 byte packets (RMON_R_P512TO1023)
Offset: 2B8h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 757. RMON Rx 512 to 1023 byte packets (RMON_R_P512TO1023)
Field
RMON_R_P512TO
RMON Rx 512 to 1023 byte packets
1023
1334/2058
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 765. RMON_R_P128TO255 field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 766. RMON_R_P256TO511 field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 767. RMON_R_P512TO1023 field descriptions
DocID027809 Rev 4
RMON_R_P128TO255
Description
RMON_R_P256TO511
Description
RMON_R_P512TO1023
Description
RM0400
Access: Read-only
Access: Read-only
Access: Read-only
