RM0400
Field
26–0
TBU0_DATA
42.5.1.41 TBU1 watchpoint control 1 register (GTMDI_TBU1_WPC1)
The GTMDI_TBU1_WPC1 register shown in
TBU1 GTM Time Base Units. These watchpoints are used to control the requests for GTM
to enter Halt state, issue watchpoint messages and also to control logic external to the
GTMDI at SoC level such as in the SPU interface.
Note: Start/Stop signals inputs to the GTMDI can overwrite the state of the WMC1 and WMC2
control bits thus controlling the Watchpoint messages behavior. In case of JTAG modifies
the WMC1 or WMC2 bits and Start/Stop signals occur at the same time also modifying the
same bits, Start/Stop signals have precedence over JTAG writes. The SEN1 and SEN2
control bits from the GTMDI_TBU1_WPC2 register need to be set in order to allow external
Start/Stop signals to control the WMC1/2 bits.
Register index: 101
31 30
R 0 0
W
RESET: 0 0
15 14
R 0 0
W
RESET: 0 0
Figure 446. TBU1 watchpoint control 1 register (GTMDI_TBU1_WPC1)
Table 499
Field
TBU1 Watchpoint 1 Compare Selection. The TSS1[1:0] field controls the type of comparison used
for TBU1 watchpoint generation.
29–28
00 TBU1 update (do not compare data)
TSS1 01 Compare TBU1 value with expected data
10 Reserved
11 Reserved
Halt Enable 1. The HEN1 Halt Enable 1 bit controls if the TBU1 event is enabled to HALT the GTM
module. If this bit is set and an event occurs on the TBU1 a Halt signal is generated to the GTM
23
which enters debug state.
HEN1
0 Disables Halt GTM
1 Enables Halt GTM

Table 498. GTMDI_TBU0_DATA field descriptions

TBU0 Watchpoint DATA. The field TBU0_DATA is used to compare against the TBU0 data.
29 28 27 26
0 0
TSS1
0 0 0 0
13 12 11 10
0 0
TSS2
0 0 0 0
describes the GTMDI_TBU1_WPC1 register functions.
Table 499. GTMDI_TBU1_WPC1 field descriptions
Description
Figure 446
25 24 23
0 0
HEN1 WMC1
0 0 0
9 8 7
0 0
HEN2 WMC2
0 0 0
Description
DocID027809 Rev 4
GTM Development Interface (GTMDI)
controls the Watchpoint issued by
22 21 20 19
0 0 0
0 0 0 0
6 5 4 3
0 0 0
0 0 0 0
18 17 16
0 0 0
0 0 0
2 1 0
0 0 0
0 0 0
935/2058
