Register Descriptions - STMicroelectronics SPC572L series Reference Manual

RM0400
Address
offset
Error Injection Channel2 Descriptor, Word1
0x304
(EICHD2.Word1)
Error Injection Channel2 Descriptor, Word2
0x308
(EICHD2.Word2)
0x30C–0x3FF
Error Injection Channel3 Descriptor, Word0
0x400
(EICHD3.Word0)
Error Injection Channel3 Descriptor, Word1
0x404
(EICHD3.Word1)
Error Injection Channel3 Descriptor, Word2
0x408
(EICHD3.Word2)
0x40C–0x4FF
Error Injection Channel4 Descriptor, Word0
0x500
(EICHD4.Word0)
Error Injection Channel4 Descriptor, Word1
0x504
(EICHD4.Word1)
Error Injection Channel4 Descriptor, Word2
0x508
(EICHD4.Word2)
0x50C–0x5FF
Error Injection Channel5 Descriptor, Word0
0x600
(EICHD5.Word0)
Error Injection Channel5 Descriptor, Word1
0x604
(EICHD5.Word1)
Error Injection Channel5 Descriptor, Word2
0x608
(EICHD5.Word2)
33.2.2

Register descriptions

Following sections describe the registers associated with this module.
33.2.2.1 Error Injection Module Configuration Register (EIMCR)
The EIM Configuration Register is used to globally enable or disable the error injection
function.
Table 333. EIM memory map(Continued)
Register
DocID027809 Rev 4
Error Injection Module (EIM)
Access Reset value
R/W 0x0000_0000
R/W 0x0000_0000
Reserved
R/W 0x0000_0000
R/W 0x0000_0000
R/W 0x0000_0000
Reserved
R/W 0x0000_0000
R/W 0x0000_0000
R/W 0x0000_0000
Reserved
R/W 0x0000_0000
R/W 0x0000_0000
R/W 0x0000_0000
Section/Page
33.2.2.3.2/689
33.2.2.3.3/690
33.2.2.3.1/688
33.2.2.3.2/689
33.2.2.3.3/690
33.2.2.3.1/688
33.2.2.3.2/689
33.2.2.3.3/690
33.2.2.3.1/688
33.2.2.3.2/689
33.2.2.3.3/690
