Flash Array Memory Map - STMicroelectronics SPC572L series Reference Manual

RM0400
29.2.1

Flash array memory map

29.2.1.1 Code flash
Partition 0 accounts for 1.5 MB of the total Flash Memory and is divided in 6 user blocks for
code storage. The first 256 KB blocks are organized as 1 × 256 KB. Remaining blocks are
256 KB.
Partition 0 also contains a reserved block named TestFlash in which some One Time
Programmable (OTP) user data is stored.
The sectorization of partition 0 of the 1584 KB Flash Memory module is shown in
Block Absolute addresses
B0BF 0x0040_4000 to 0x0040_5FFF
B0F1 0x0100_0000 to 0x0103_FFFF
B0F2 0x0104_0000 to 0x0107_FFFF
B0F3 0x0108_0000 to 0x010B_FFFF
B0F4 0x010C_0000 to 0x010F_FFFF
B0F5 0x0110_0000 to 0x0113_FFFF
B0F6 0x0114_0000 to 0x0117_FFFF
—
—
—
—
—
—
B0UT 0x0040_0000 to 0x0040_1FFF
B0TF 0x0040_8000 to 0x0040_BFFF
29.2.1.2 Data flash
Data flash is allocated in partition 1 of the Flash Memory module in 2 × 16 blocks destined
for data storage.
The Data Flash sectorization of the Flash Memory module is listed below.
Block Absolute addresses
B1F0 0x0080_0000 to 0x0080_3FFF
B1F1 0x0080_4000 to 0x0080_7FFF
—
Table 293. Flash memory partition 0 memory map
256 KB
256 KB
256 KB
256 KB
256 KB
256 KB
—
—
—
—
—
—
16 KB
Table 294. Flash Memory Partition 1 memory map
Size
16 KB
16 KB
—
