RM0400
Field
11–0
RAM_ADDR
42.5.1.19 DPLL data trace control register (GTMDI_DPLL_DTC)
The GTMDI_DPLL_DTC register shown in
transmission.
Register index: 46
31 30
R 0 0
W
RESET: 0 0
15 14
R 0 0
W
RESET: 0 0
Note: Start/Stop signals inputs to the GTMDI can overwrite the state of the DMC control bit thus
controlling the Data Trace messages behavior. In case of JTAG modifies the DMC bit and
Start/Stop signals occur at the same time also modifying the same bit, Start/Stop signals
have precedence over JTAG writes. The SEN control bit from the GTMDI_DPLL_DTC
register need to be set in order to allow external Start/Stop signals to control the DMC bit.
Table 477
Field
Read/Write Control. This bit controls DPLL data trace message transmission.
00 Transmits only memory reads
13–12
01 Transmits only memory writes
RWC
10 Transmits all memory accesses
11 Reserved
RAM Module Selection. This field selects a DPLL memory module for data tracing.
00 RAM1a selected for data tracing
9–8
01 RAM1b selected for data tracing
RAMSEL
10 RAM2 selected for data tracing
11 Reserved

Table 476. GTMDI_DPLL_WPC5 field descriptions

RAM Address Compare. The RAM_ADDR[11:0] field defines the address value that is
compared against the address for write and read DPLL RAM accesses. Before the
comparison is executed the RAM_ADDR_MASK should be considered thus masking
corresponding bits. A masked bit is always considered a match.
Note: DPLL module has three RAM modules with different address widths. The address
value in the RAM_ADDR field and the RAM address should be right aligned in order
to be compared.
29 28 27 26
0 0 0 0
0 0 0 0
13 12 11 10
0 0
RWC
0 0 0 0
Figure 424. DPLL data trace control register (GTMDI_DPLL_DTC)
describes the GTMDI_DPLL_DTC register functions.
Table 477. GTMDI_DPLL_DTC field descriptions
DocID027809 Rev 4
GTM Development Interface (GTMDI)
Description
Figure 424
25 24 23 22
0 0 0 0
0 0 0 0
9 8 7 6
0
RAMSEL DMC
0 0 0 0
Description
controls data trace message
21 20 19 18
0 0 0 0
0 0 0 0
5 4 3 2
0 0
STSEL
0 0 0 0
17 16
0 0
0 0
1 0
0
SEN
0 0
911/2058
