RM0400
Table 248. Auxiliary Clock 0 Divider 0 Configuration Register (CGM_AC0_DC0) field
Field
Divider Division Value — The resultant peripheral clock will have a period 'DIV + 1' times that of auxiliary
12–15
clock 0. If DE is set to 0 (divider 0 is disabled), any write access to the DIV field is ignored and the
DIV
peripheral clock remains disabled.
16–31 Reserved
24.3.1.17 Auxiliary Clock 0 Divider 1 Configuration Register (CGM_AC0_DC1)
This register controls auxiliary clock 0 divider 1.
Note: Byte and half-word write accesses are not allowed for this register. Such accesses do not
result in an exception, but the value is not loaded with the new value.
Address 0x080C
0 1 2
R 0 0
DE
W
Reset 0 0 0
16 17 18
R 0 0 0
W
Reset 0 0 0
Figure 197. Auxiliary Clock 0 Divider 1 Configuration Register (CGM_AC0_DC1)

Table 249. Auxiliary Clock 0 Divider 1 Configuration Register (CGM_AC0_DC1) field descriptions

Field
Divider Enable
0
0 Disable auxiliary clock 0 divider 1
DE
1 Enable auxiliary clock 0 divider 1
1–8 Reserved
Divider Division Value — The resultant Sigma-Delta ADC clock will have a period 'DIV + 1' times that of
9–15
auxiliary clock 0. If DE is set to 0 (divider 1 is disabled), any write access to the DIV field is ignored and
DIV
the Sigma-Delta ADC clock remains disabled.
16–31 Reserved
24.3.1.18 Auxiliary Clock 0 Divider 2 Configuration Register (CGM_AC0_DC2)
This register controls auxiliary clock 0 divider 2.
Note: Byte and half-word write accesses are not allowed for this register. Such accesses do not
result in an exception, but the value is not loaded with the new value.
descriptions(Continued)
Access: User read/write, Supervisor read/write, Test read/write
3 4 5 6
0 0 0 0
0 0 0 0
19 20 21 22
0 0 0 0
0 0 0 0
DocID027809 Rev 4
Clock Generation Module (MC_CGM)
Description
7 8 9 10
0 0
0 0 0 0
23 24 25 26
0 0 0 0
0 0 0 0
Description
11 12 13 14
DIV
0 0 0 0
27 28 29 30
0 0 0 0
0 0 0 0
511/2058
15
0
31
0
0
