RM0400
.
Offset 0x00C
0 1
R
M0AP
W
Reset 1 1
16 17 18
R
M8AP
W
Reset 1 1
Name
0–1
M0AP
2–3
M1AP
4–5
M2AP
6–7
M3AP
2 3 4 5
M1AP M2AP
1 1 1 1
19 20 21
M9AP M10AP
1 1 1 1
Figure 242. PFAPR register

Table 286. PFAPR field descriptions

Master 0 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
Master 1 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
Master 2 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
Master 3 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
DocID027809 Rev 4
Flash memory controller (PFLASH Controller)
6 7 8 9
M3AP M4AP
1 1 1 1
22 23 24 25
M11AP M12AP
1 1 1 1
Description
Access: Supervisor
10 11 12 13
M5AP M6AP
1 1 1 1
26 27 28 29
M13AP M14AP
1 1 1 1
Read/Write
14 15
M7AP
1 1
30 31
M15AP
1 1
