Error Reporting Module (ERM)
Offset 0x010
0 1
R
W
Reset 0 0
16 17 18
R
W
Reset 0 0
Field
Memory 0 Single-Bit Correction Event
This field is initialized by hardware reset.
Write '1' to clear this field.
0
Write '1' to clear this field also deasserts the corresponding interrupt notification if
SBC0
ERM_CR[ESCIE0] is enabled.
0 No single-bit correction event on Memory 0 detected
1 Single-bit correction event on Memory 0 detected
Note: Refer to the device configuration chapter for details on Memory 0 mapping.
Memory 0 Non-Correctable Error Event
This field is initialized by hardware reset.
Write '1' to clear this field also deasserts the corresponding interrupt notification if
1
ERM_CR[ENCIE0] is enabled.
NCE0
0 No non-correctable error event on Memory 0 detected
1 Non-correctable error event on Memory detected
Note: Refer to the device configuration chapter for details on Memory 0 mapping.
Memory 1 Single-Bit Correction Event
This field is initialized by hardware reset.
Write '1' to clear this field.
4
Write '1' to clear this field also deasserts the corresponding interrupt notification if
SBC1
ERM_CR[ESCIE1] is enabled.
0 No single-bit correction event on Memory 1 detected
1 Single-bit correction event on Memory 1 detected
Note: Refer to the device configuration chapter for details on Memory 1 mapping.
Memory 1 Non-Correctable Error Event
This field is initialized by hardware reset.
Write '1' to clear this field also deasserts the corresponding interrupt notification if
5
ERM_CR[ENCIE1] is enabled.
NCE1
0 No non-correctable error event on Memory 1 detected
1 Non-correctable error event on Memory 1 detected
Note: Refer to the device configuration chapter for details on Memory 1 mapping.
678/2058
2 3 4 5
0 0
0 0 0 0
19 20 21
0 0
0 0 0 0
Figure 294. ERM Status Register (ERM_SR)
