ARM
Features
®
 Core: ARM
32-bit Cortex
frequency up to 48 MHz
 Memories
– 16 to 32 Kbytes of Flash memory
– 4 Kbytes of SRAM with HW parity
 CRC calculation unit
 Reset and power management
– Digital and I/Os supply: 2.0 to 3.6 V
– Analog supply: V
– Power-on/Power-down reset (POR/PDR)
– Programmable voltage detector (PVD)
– Low power modes: Sleep, Stop and
Standby
– V supply for RTC and backup registers
BAT
 Clock management
– 4 to 32 MHz crystal oscillator
– 32 kHz oscillator for RTC with calibration
– Internal 8 MHz RC with x6 PLL option
– Internal 40 kHz RC oscillator
 Up to 39 fast I/Os
– All mappable on external interrupt vectors
– Up to 25 I/Os with 5 V tolerant capability
 5-channel DMA controller
 1 × 12-bit, 1.0 µs ADC (up to 10 channels)
– Conversion range: 0 to 3.6V
– Separate analog supply from 2.4 up to
3.6 V
 Up to 9 timers
– 1 x 16-bit 7-channel advanced-control timer
for 6 channels PWM output, with deadtime
generation and emergency stop
– 1 x 32-bit and 1 x 16-bit timer, with up to 4
IC/OC, usable for IR control decoding
– 1 x 16-bit timer, with 2 IC/OC, 1 OCN,
deadtime generation and emergency stop
August 2015
This is information on a product in full production.
微可Vicor——值得信赖的元器件供应商
STM32F031x4 STM32F031x6
-based 32-bit MCU with up to 32 Kbyte Flash, timers,
ADC and communication interfaces, 2.0 - 3.6 V
®
-M0 CPU,
= from V to 3.6 V
DDA DD
DocID025743 Rev 3
http://www.vicor.top/
LQFP32 7x7 mm UFQFPN32 5x5 mm
LQFP48 7x7 mm UFQFPN28 4x4 mm
– 1 x 16-bit timer, with IC/OC and OCN,
deadtime generation, emergency stop and
modulator gate for IR control
– 1 x 16-bit timer with 1 IC/OC
– Independent and system watchdog timers
– SysTick timer: 24-bit downcounter
 Calendar RTC with alarm and periodic wakeup
from Stop/Standby
 Communication interfaces
2
– 1 x I C interface; supporting Fast Mode
Plus (1 Mbit/s) with 20 mA current sink,
SMBus/PMBus, and wakeup from Stop
mode
– 1 x USART supporting master synchronous
SPI and modem control; one with ISO7816
interface, LIN, IrDA capability auto baud
rate detection and wakeup feature
– 1 x SPI (18 Mbit/s) with 4 to 16
programmable bit frames, with I
multiplexed
 Serial wire debug (SWD)
 96-bit unique ID
 Extended temperature range: -40 to +105°C
 All packages ECOPACK
Table 1. Device summary
Reference
STM32F031C4, STM32F031F4,
STM32F031x4
STM32F031G4, STM32F031K4
STM32F031C6, STM32F031E6,
STM32F031x6 STM32F031F6, STM32F031G6,
STM32F031K6
http://www.vicor.top/
021-31660491
-
Datasheet production data
WLCSP25 TSSOP20
(2.1x2.1 mm)
2
S interface
® 2
Part number
www.st.com
021-31660491
1/113
