Fast Ethernet Controller (FEC)
48.4.30 RMON Tx packets > MAX_FL bytes, good CRC (RMON_T_OVERSIZE)
Offset: 218h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 719. RMON Tx packets > MAX_FL bytes, good CRC (RMON_T_OVERSIZE)
Field
RMON_T_OVERSIZE
48.4.31 RMON Tx packets < 64 bytes, bad CRC (RMON_T_FRAG)
Offset: 21Ch
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 720. RMON Tx packets < 64 bytes, bad CRC (RMON_T_FRAG)
Field
RMON_T_FRAG RMON Tx packets < 64 bytes, bad CRC
48.4.32 RMON Tx packets > MAX_FL bytes, bad CRC (RMON_T_JAB)
Offset: 220h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 721. RMON Tx packets > MAX_FL bytes, bad CRC (RMON_T_JAB)
Field
RMON_T_JAB RMON Tx packets > MAX_FL bytes, bad CRC
1322/2058
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 729. RMON_T_OVERSIZE field descriptions
RMON Tx packets > MAX_FL bytes, good CRC
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 730. RMON_T_FRAG field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 731. RMON_T_JAB field descriptions
DocID027809 Rev 4
RMON_T_OVERSIZE
Description
RMON_T_FRAG
Description
RMON_T_JAB
Description
RM0400
Access: Read-only
Access: Read-only
Access: Read-only
