GTM101 Integration (GTMINT) Module
Offset
RAM Region 1a (0.288 KB for 96 words of 24 bits)
ACTION_n Position/Value action request
0x28200 + n*0x0004
Register (PSAn), n = 0...23
0x28260 + ACTION_m time to react before PSAm
m*0x0004 (DLAm), m = 0...23
Number of TRIGGER/STATE increments to
0x282C0 + n*0x0004
ACTION_n (NAn), n = 0...23
0x28320 + Calculated relative time to ACTION_m
m*0x0004 (DTAm), m = 0...23
0x28380 – 0x283FC Reserved on this RAM
DPLL RAM Region 1b (0.375 KB for 128 words of 24 bits)
TRIGGER signal information stored
Note: The switch of the LSB address bits is performed using the SWON register at 0x0020.
Actual signal TRIGGER time stamp register
0x28400/ 0x0404
TRIGGER_TS (TS_T)
Previous signal TRIGGER time stamp
0x28404/ 0x0400
register TRIGGER_TS_old (TS_T_old)
Actual signal TRIGGER filter and signal
0x28408
value (FTV_T)
0x2840C
STATE signal information stored
Note: The switch of the LSB address bits is
performed using the SWON register at
0x0020.
Actual signal STATE time stamp register
0x28410/ 0x0414
STATE_TS (TS_S)
Previous signal STATE time stamp register
0x28414/ 0x0410
STATE_TS_old (TS_S_old)
Actual signal STATE filter and signal value
0x28418
(FTV_S)
0x2841C
0x28420 TRIGGER hold time min value (THMI)
0x28424 TRIGGER hold time max value (THMA)
Measured last pulse time from valid to invalid
0x28428
TRIGGER slope (THVAL)
0x2842C
Time out value of active TRIGGER slope
0x28430
(TOV)
