Embedded Flash Memory (MP55)
Field
Reserved (Read/Write).
2-21
Writes have no effect. For compatibility purposes, any writes should be '0'.
Next Array Integrity Break Point (Read/Clear)
If AIBPE is set, NAIBP is set once a single bit correction (if enabled) or double bit detection is
noted during the Array Integrity test. NAIBP is not writable to '1' but may be cleared to '0'.
22
Clearing NAIBP to '0' enables the Array Integrity operation to be re-started after a breakpoint
is encountered. If the Array Integrity operation completes without encountering another
NAIBP
correction or detection, AID is set with NAIBP remaining '0'.
0 Array Integrity is not currently at a break point.
1 Array Integrity is at a break point.
Array Integrity Break Point Enable. (Read/Write)
To enable breakpoints during an Array Integrity test, AIBPE may be set. When breakpoints
are enabled, if the run has been started with MCR[ERR] (and MCR[SBC] when
23
UT0[SBCE]=1) flag cleared, on the eventual occurrence of a breakpoint condition, MCR flags
and ADR value may be updated. See NAIBP description for more information about Array
AIBPE
Integrity breakpoints.
0 Array Integrity breakpoints are not enabled.
1 Array Integrity breakpoints are enabled during Array Integrity Checks.
24 Reserved
Array Integrity Suspend (Read/Write).
AISUS toggles Suspend of an Array Integrity - Margin Read Operation.
AISUS can be written to '1' only when AID is low
25
AISUS can be written to '0' only when AID is high.
AISUS
Attempting to Write AISUS and AIE on the same clock cycle results in only AIE being written.
0 Array Integrity sequence not suspended.
1 Array Integrity sequence is suspended.
Margin Read Enable (Read/Write)
MRE enables margin reads to be done.
MRE combined with MRV enables User Margin mode reads to be done.
Margin reads run on a block-by-block basis in linear address sequence selected by SEL0,
26
SEL1 and SEL2.
MRE
This bit is not accessible when MCR[DONE] or UT0[AID] are low or if AISUS or NAIBP are
high: reading returns indeterminate data while writing has no effect.
0 Margin Read is not enabled.
1 Margin Read is enabled.
Margin Read Value (Read/Write)
If MRE is high, MRV selects the margin level that is being checked. Margin can be checked to
an erased level (MRV=1) or to a programmed level (MRV=0).
27
This bit is not accessible whenever MCR[DONE] or UT0[AID] are low or if AISUS or NAIBP
MRV
are high: reading returns indeterminate data while writing has no effect.
0 Zero's (programmed) margin reads are requested (if MRE=1).
1 One's (erased) margin reads are requested (if MRE=1).
Reserved (Read/Write).
28
Write this bit has no effect. It's suggested for compatibility to Write at 0.
