Analog-to-digital converter (ADC) configuration
Name
ICDSRn Internal Channel DMA Select Registers
WTHRHLR0–3 Watchdog Threshold Registers 0–3
CTRn Conversion Timing Registers 0–3
ICNCMRn Internal Channel Normal Conversion Mask Registers
ICJCMRn Internal Channel Injected Conversion Mask Registers
PDEDR Power Down Exit Delay Register
ICDRn Internal Channel Data Registers 0–95
WTHRHLR4–15 Watchdog Threshold Registers 4–15
ICWSELRn Internal Channel Watchdog Select Registers
ICWENRn Internal Channel Watchdog Enable Registers
ICAWORRn Internal Channel Analog Watchdog Out of Range Registers

Table 348. SAR ADC test channel register descriptions (SARB only)

Name
TCIPR Test Channel Interrupt Pending Register
TCIMR Test Channel Interrupt Mask Register
TCDSR Test Channel DMA Select Register
TCNCMR Test Channel Normal Conversion Mask Register
TCJCMR Test Channel Injected Conversion Mask Register
TCWSELRn Test Channel Watchdog Select Register
TCWENR Test Channel Watchdog Enable Register
TCAWORR Test Channel Analog Watchdog Out of Range Register
TCCAPRn Test Channel Connection with Analog Pin Registers
TCDRn Test Channel Data Register 96–127
Table 349. SAR ADC external channel register descriptions (SARB only)
Name
ECDSDR External Channel Decode Signals Delay Register
ECIPRn External Channel Interrupt Pending Registers
ECIMRn External Channel Interrupt Mask Registers
ECDSRn External Channel DMA Select Registers
ECNCMRn External Channel Normal Conversion Mask Registers
ECJCMRn External Channel Injected Conversion Mask Registers
ECWSELRn External Channel Watchdog Select Registers
710/2058
Table 347. SAR ADC register descriptions(Continued)
DocID027809 Rev 4
Description
Description
Description
RM0400
User access
read/write
read/write
read/write
read/write
read/write
read/write
mixed
read/write
read/write
read/write
read
User access
read
read/write
read/write
read/write
read/write
read/write
read/write
read
read/write
read/write
User access
read/write
read
read/write
read/write
read/write
read/write
read/write
