STMicroelectronics SPC572L series Reference Manual page 567

RM0400
Name
20–21
M10AP
22–23
M11AP
24–25
M12AP
26–27
M13AP
28–29
M14AP
30–31
M15AP
Table 286. PFAPR field descriptions(Continued)
Master 10 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
Master 11 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
Master 12 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
Master 13 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
Master 14 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
Master 15 Access Protection. This field controls whether read and write accesses to the
flash are allowed based on the master ID of a requesting master. These fields are initialized
by hardware reset.
00 No accesses may be performed by this master
01 Only read accesses may be performed by this master
10 Only write accesses may be performed by this master
11 Both read and write accesses may be performed by this master
DocID027809 Rev 4
Flash memory controller (PFLASH Controller)
Description
567/2058
590
