36.5.1.3 Interrupt Status Register (ISR)
Offset 0x010
0 1
R 0 0
W
Reset 0 0
16 17
R 0 0
W
Reset 0 0
1. Only available with cross-triggering unit (CTU) feature.
Field
Reserved
0–25
Write of any value has no effect; read value is always 0.
26–27 Reserved
End of injected channel conversion interrupt flag
This bit indicates the end of conversion for an injected channel.
28
0 End of conversion of injected channel has not occurred since the last time the flag is cleared.
JEOC
1 End of conversion of injected channel has occurred or the flag has not been cleared since the
last end of conversion occurrence.
End of injected chain conversion interrupt flag
This bit indicates the end of conversion for an injected chain.
29
0 End of conversion of injected chain has not occurred since the last time the flag is cleared.
JECH
1 End of conversion of injected chain has occurred or the flag has not been cleared since the last
end of conversion occurrence.
End of normal channel conversion interrupt flag
This bit indicates the end of conversion for a normal channel.
30
0 End of conversion of normal channel has not occurred since the last time the flag is cleared.
NEOC
1 End of conversion of normal channel has occurred or the flag has not been cleared since the
last end of conversion occurrence.
End of normal chain conversion interrupt flag
This bit indicates the end of conversion for an normal chain.
31
0 End of conversion of normal chain has not occurred since the last time the flag is cleared.
NECH
1 End of conversion of normal chain has occurred or the flag has not been cleared since the last
end of conversion occurrence.
2 3 4 5
0 0 0 0
0 0 0 0
18 19 20 21
0 0 0 0
0 0 0 0
Figure 331. Interrupt Status Register (ISR)

Table 372. ISR field descriptions

DocID027809 Rev 4
6 7 8 9
0 0 0 0
0 0 0 0
22 23 24 25
0 0 0 0
0 0 0 0
Description
Access: User Read Only
10 11 12 13
0 0 0 0
0 0 0 0
26 27 28 29
w1c w1c w1c w1c
0 0 0 0
14 15
0 0
0 0
30 31
w1c w1c
0 0
