Table 561. Txbcr Field Descriptions - STMicroelectronics SPC572L series Reference Manual

CAN Subsystem
Field
Cancellation Request
Each Tx Buffer has its own Cancellation Request bit. Writing a '1' will set the corresponding
Cancellation Request bit; writing a '0' has no impact. This enables the Host to set cancellation
0:31
requests for multiple Tx Buffers with one write to TXBCR. TXBCR bits are set only for those Tx
CR
Buffers configured via TXBC. The bits remain set until the corresponding bit of TXBRP is reset.
0 No cancellation pending
1 Cancellation pending
44.3.5.2.37 Tx Buffer Transmission Occurred Register (TXBTO)
Address: 0x00D8
0 1
R
W
Reset 0 0
16 17 18
R
W
Reset 0 0
Table 562. Tx Buffer Transmission Occurred field description
Field
[0:31]
TO
1042/2058

Table 561. TXBCR field descriptions

2 3 4 5
0 0 0 0
19 20 21
0 0 0 0
Figure 507. Tx Buffer Transmission Occurred register
Transmission Occurred.
Each Tx Buffer has its own Transmission Occurred bit. The bits are set when the
corresponding TXBRP bit is cleared after a successful transmission. The bits are reset
when a new transmission is requested by writing a '1' to the corresponding bit of register
TXBAR.
0 No transmission occurred
1 Transmission occurred
Description
6 7 8 9
TO
0 0 0 0
22 23 24 25
TO
0 0 0 0
Description
DocID027809 Rev 4
10 11 12 13
0 0 0 0
26 27 28 29
0 0 0 0
RM0400
Access: Read
14 15
0 0
30 31
0 0
