Fast Ethernet Controller (FEC)
48.4.72

Count of received frames not counted correctly (IEEE_R_DROP)

Offset: 2C8h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 761. Count of received frames not counted correctly (IEEE_R_DROP)
Field
IEEE_R_DROP Count of received frames not counted correctly
48.4.73 Frames received OK (IEEE_R_FRAME_OK)
Offset: 2CCh
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Field
IEEE_R_FRAME_
Frames received OK
OK
48.4.74 Frames received with CRC error (IEEE_R_CRC)
Offset: 2D0h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 763. Frames received with CRC error (IEEE_R_CRC)
Field
IEEE_R_CRC Frames received with CRC error
1336/2058
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 771. IEEE_R_DROP field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Figure 762. Frames received OK (IEEE_R_FRAME_OK)
Table 772. IEEE_R_FRAME_OK field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 773. IEEE_R_CRC field descriptions
DocID027809 Rev 4
IEEE_R_DROP
Description
IEEE_R_FRAME_OK
Description
IEEE_R_CRC
Description
RM0400
Access: Read-only
Access: Read-only
Access: Read-only
