RM0400 Successive Approximation Register Analog-to-Digital Converter (SARADC) Digital Inter-
Field
0–3
4–15
THRH
16–19
20–31
THRL
The number of WTHRHLR registers depends on num_watchdog generic parameter
configuration. In case num_watchdog is zero, these registers are not implemented.
The length of the threshold field depends on the generic resolution.
36.5.1.18 Internal Channel Watchdog Select Registers (ICWSELR0–ICWSELR11)
These registers contain WSEL_CHx[3:0] bitfields to select the threshold register which
provides the values to be used for upper and lower bounds for channel x.
The Watchdog select registers to channel association is described in
Offset 0x2B0–0x2DC
0 1
R
WSEL_CH7
W
Reset 0 0
16 17
R
WSEL_CH3
W
Reset 0 0
Figure 346. Internal Channel Watchdog Select Registers (ICWSELR0–ICWSELR11)
Field
4*x+3 : 4*x
WSEL_CH[x]
Table 391. WTHRHLR4–WTHRHLR15 field descriptions
Reserved
Write of any value has no effect; read value is always 0.
High threshold value for channel x
Reserved
Write of any value has no effect; read value is always 0.
Low threshold value for channel x
2 3 4 5
WSEL_CH6
0 0 0 0
18 19 20 21
WSEL_CH2
0 0 0 0
Table 392. ICWSELR0–ICWSELR11 field descriptions
Watchdog select for channel x
0000 THRHLR0 register is selected
0001 THRHLR1 register is selected
0010 THRHLR2 register is selected
...
1110 THRHLR14 register is selected
1111 THRHLR15 register is selected
DocID027809 Rev 4
Description
6 7 8 9
WSEL_CH5
0 0 0 0
22 23 24 25
WSEL_CH1
0 0 0 0
Description
Table 393.
Access: User Read/Write
10 11 12 13
WSEL_CH4
0 0 0 0
26 27 28 29
WSEL_CH0
0 0 0 0
14 15
0 0
30 31
0 0
