Embedded Flash Memory (MP55)
Field
Number of 256K blocks. (read only)
00000 Zero 256K blocks.
00001 One 256K block.
00010 Two 256K blocks.
00011 Three 256K blocks.
00100 Four 256K blocks.
00101 Five 256K blocks.
00110 Six 256K blocks.
3–7
00111 Seven 256K blocks
n256K
01000 Eight 256K blocks.
01001 Nine 256K blocks.
01010 Ten 256K blocks.
....................................................................................
11100 Twenty-Eight 256K blocks (7.0 MB total).
11101 Twenty-Nine 256K blocks (7.25 MB total).
11110 Thirty 256K blocks (7.5 MB total).
11111 Thirty-one 256K blocks (7.75 MB total).
Number of 64 KB blocks in high space. (read only)
000 Zero 64 KB blocks.
001 Two 64 KB blocks.
010 Four 64 KB blocks.
8–10
011 Six 64 KB blocks.
n64Kh
100 Eight 64 KB blocks.
101 Reserved.
110 Reserved.
111 Reserved.
Number of 32 KB blocks in high space. (read only)
00 Zero 32 KB blocks.
11–12
01 Two 32 KB blocks.
n32Kh
10 Four 32 KB blocks.
11 Reserved.
Number of 16 KB blocks in high space. (read only)
000 Zero 16 KB blocks.
001 Two 16 KB blocks.
010 Four 16 KB blocks.
13–15
011 Six 16 KB blocks.
n16Kh
100 Eight 16 KB blocks.
101 Reserved.
110 Reserved.
111 Reserved.
608/2058
Table 300. MCRE field descriptions(Continued)
DocID027809 Rev 4
Description
