Table 346. Sarb Analog Test Channel Assignment - STMicroelectronics SPC572L series Reference Manual

Analog-to-digital converter (ADC) configuration
SARB input
channel
96
97–103
104
105–108
109
110–119
120
121
122–123
124
125
126
127
34.2.2.9.2 SARB interface to PMC
The connection of the PMC to SARB ADC is shown in
connects to the PMC. The PMC contains an analog mux that passes internal voltage nodes
in addition to those given in
PMC digital interface. To convert an internal PMC voltage, the user programs the PMC
analog mux selection, and then programs SARB to convert PMC channel 110. See the
Power Management chapter of this document for more info on additional internal voltages
that can be read by the SARB ADC.
708/2058

Table 346. SARB analog test channel assignment

VDD_HV_PMC
Reserved
VDD_LV
Reserved
VSS_HV_ADV (ADC Ground Voltage)
Reserved
Temperature Sensor
ADC Bandgap Reference
Reserved
SAR BIAS 0—V
SS_HV_ADR
SAR BIAS 1—1/3 × (V
DD_HV_ADR
impedance
SAR BIAS 2—2/3 × (V
DD_HV_ADR
impedance
SAR BIAS 3—3/3 × (V
DD_HV_ADR
impedance
Table 346. The PMC mux is programmed in a register in the
DocID027809 Rev 4
Description
Ω
through 20 k source impedance
– V ) through 20 k
SS_HV_ADR
– V ) through 20 k
SS_HV_ADR
– V ) through 20 k
SS_HV_ADR
Figure 313. SARB ADC channel 110
