Clock Generation Module (MC_CGM)

Table 252. Auxiliary Clock 1 Select Status Register (CGM_AC1_SS) field descriptions

Field
0–3 Reserved
Auxiliary Clock 1 Source Selection Status — This value indicates the current source for auxiliary
clock 1.
0000 reserved
0001 XOSC
0010 PLL0 PHI
0011 PLL0 PHI1
0100 reserved
0101 reserved
4–7
0110 reserved
0111 reserved
SELSTAT
1000 reserved
1001 reserved
1010 reserved
1011 reserved
1100 reserved
1101 reserved
1110 reserved
1111 reserved
8–31 Reserved
24.3.1.21 Auxiliary Clock 1 Divider 0 Configuration Register (CGM_AC1_DC0)
This register controls auxiliary clock 1 divider 0.
Note: Byte and half-word write accesses are not allowed for this register. Such accesses do not
result in an exception, but the value is not loaded with the new value.
Address 0x0828
0 1 2
R 0 0
DE
W
Reset 0 0 0
16 17 18
R 0 0 0
W
Reset 0 0 0
Figure 201. Auxiliary Clock 1 Divider 0 Configuration Register (CGM_AC1_DC0)
Table 253. Auxiliary Clock 1 Divider 0 Configuration Register (CGM_AC1_DC0) field
Field
Divider Enable
0
0 Disable auxiliary clock 1 divider 0
DE
1 Enable auxiliary clock 1 divider 0
1–8 Reserved
514/2058
Access: User read/write, Supervisor read/write, Test read/write
3 4 5 6
0 0 0 0
0 0 0 0
19 20 21 22
0 0 0 0
0 0 0 0
descriptions
DocID027809 Rev 4
Description
7 8 9 10
0 0
0 0 0 0
23 24 25 26
0 0 0 0
0 0 0 0
Description
RM0400
11 12 13 14
DIV
0 0 0 0
27 28 29 30
0 0 0 0
0 0 0 0
15
0
31
0
