Fast Ethernet Controller (FEC)
48.4.60 RMON Rx packets > MAX_FL bytes, good CRC (RMON_R_OVERSIZE)
Offset: 298h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 749. RMON Rx packets > MAX_FL bytes, good CRC (RMON_R_OVERSIZE)
Field
RMON_R_OVERSIZE
48.4.61 RMON Rx packets < 64 bytes, bad CRC (RMON_R_FRAG)
Offset: 29Ch
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 750. RMON Rx packets < 64 bytes, bad CRC (RMON_R_FRAG)
Field
RMON_R_FRAG RMON Rx packets < 64 bytes, bad CRC
48.4.62 RMON Rx packets > MAX_FL bytes, bad CRC (RMON_R_JAB)
Offset: 2A0h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 751. RMON Rx packets > MAX_FL bytes, bad CRC (RMON_R_JAB)
Field
RMON_R_JAB RMON Rx packets > MAX_FL bytes, bad CRC
1332/2058
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 759. RMON_R_OVERSIZE field descriptions
RMON Rx packets > MAX_FL bytes, good CRC
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 760. RMON_R_FRAG field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 761. RMON_R_JAB field descriptions
DocID027809 Rev 4
RMON_R_OVERSIZE
Description
RMON_R_FRAG
Description
RMON_R_JAB
Description
RM0400
Access: Read-only
Access: Read-only
Access: Read-only
