RM0400
Table 482
Field
28–0
DATA1H
42.5.1.25 ARU watchpoint DATA1L register (GTMDI_ARU_DATA1L)
The ARU Watchpoint DATA1L low word shown in
against the low word of the ARU Debugging Channel 1. The address for the channel to be
monitored is defined by the Host CPU in the GTM IP ARU_DBG_ACCESS1 register.
Register index: 55
31 30
R 0 0
W
RESET: 0 0
15 14
R
W
RESET: 0 0
Table 483
Field
28–0
DATA1L
42.5.1.26 ARU data trace control register (GTMDI_ARU_DTC)
The GTMDI_ARU_DTC register shown in
transmission. The GTM Module selects two ARU addresses to be monitored, using the ARU
Debugging Channels 0 and 1. The data trace for these two channels is controlled by
DMC1/2 bits in this register. Once enabled, messages are generated as soon as a valid
data is identified in one of the ARU Debugging Channels, 0 or 1.
Note: Start/Stop signals inputs to the GTMDI can overwrite the state of the DMC1 and DMC2
control bits thus controlling the Data Trace messages behavior. In case of JTAG modifies
the DMC1 or DMC2 bits and Start/Stop signals occur at the same time also modifying the
same bits, Start/Stop signals have precedence over JTAG writes. The SEN1 and SEN2
control bits need to be set in order to allow external Start/Stop signals to control the DMC1/2
bits.
describes the GTMDI_ARU_DATA1H register functions.

Table 482. GTMDI_ARU_DATA1H field descriptions

Watchpoint DATA1H. This field is compared against the high word of the ARU Debugging
Channel 1.
29 28 27 26
0
0 0 0 0
13 12 11 10
0 0 0 0
Figure 430. ARU Watchpoint DATA1L (GTMDI_ARU_DATA1L)
describes the GTMDI_ARU_DATA1L register functions.
Table 483. GTMDI_ARU_DATA1L field descriptions
Watchpoint DATA1L. This field is compared against the low word of the ARU Debugging
Channel 1.
DocID027809 Rev 4
GTM Development Interface (GTMDI)
Description
Figure 430
25 24 23 22
DATA1L[28:16]
0 0 0 0
9 8 7 6
DATA1L[15:0]
0 0 0 0
Description
Figure 431 controls the ARU data trace message
is used to be compared
21 20 19 18
0 0 0 0
5 4 3 2
0 0 0 0
17 16
0 0
1 0
0 0
917/2058
