Fast Ethernet Controller (FEC)
48.4.42

Count of transmitted frames not counted correctly (IEEE_T_DROP)

Offset: 248h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 731. Count of transmitted frames not counted correctly (IEEE_T_DROP)
Field
IEEE_T_DROP Count of transmitted frames not counted correctly
48.4.43 Frames transmitted OK (IEEE_T_FRAME_OK)
Offset: 24Ch
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Field
IEEE_T_FRAME_OK Frames transmitted OK
48.4.44 Frames transmitted with single collision (IEEE_T_1COL)
Offset: 250h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 733. Frames transmitted with single collision (IEEE_T_1COL)
Field
IEEE_T_1COL Frames transmitted with single collision
1326/2058
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 741. IEEE_T_DROP field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Figure 732. Frames transmitted OK (IEEE_T_FRAME_OK)
Table 742. IEEE_T_FRAME_OK field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 743. IEEE_T_1COL field descriptions
IEEE_T_DROP
Description
IEEE_T_FRAME_OK
Description
IEEE_T_1COL
Description
