Embedded Flash Memory (MP55)
Field
Address 23-3 (read only)
The Address Register provides the first failing address in the event of ECC error (MCR[EER] set)
or the first failing address in the event of RWW error (MCR[RWE] set), or the address of a failure
that may have occurred in a FPEC operation (MCR[PEG] cleared). The Address Register also
provides the first address at which a ECC single error correction occurs (MCR[EDC] set) if the
SoC is configured to show this feature through UT0[SBCE].
The ECC double error detection takes the highest priority, followed by the RWW error, the FPEC
error and the ECC single error correction. When accessed, ADR provides the address related to
8–28
the first event occurred with the highest priority.
ADDR[23:3]
This address is always a doubleword address that selects 64 bits.
In case of a simultaneous ECC Double Error Detection on more than one doubleword of the
same page, bits ADDR[4] and ADDR[3] output '0'. The same is valid for a simultaneous ECC
Single Error Correction on more than one doubleword of the same page.
In User mode the Address Register is read only.
Address given is in flash format and has to be intended as in the flash memory Map: offset
respect to absolute address.
Reserved (read only).
29–31
Writing tothis bit has no effect and a read always returns 0.
Block
B0BF
B0F1
B0F2
B0F3
B0F4
B0F5
B0F6
—
—
—
—
—
—
B0UT
B0TF
618/2058
Table 309. ADR field descriptions(Continued)

Table 310. Flash memory partition 0 addresses mapping

Flash format addresses
0x0080_6000 to 0x0080_7FFF
0x0000_0000 to 0x0003_FFFF
0x0004_0000 to 0x0007_FFFF
0x0008_0000 to 0x000B_FFFF
0x000C_0000 to 0x000F_FFFF
0x0010_0000 to 0x0013_FFFF
0x0014_0000 to 0x0017_FFFF
0x0080_4000 to 0x0080_5FFF
0x0080_8000 to 0x0080_BFFF
DocID027809 Rev 4
Description
—
—
—
—
—
—
Absolute addresses
0x0040_4000 to 0x0040_5FFF
0x0100_0000 to 0x0103_FFFF
0x0104_0000 to 0x0107_FFFF
0x0108_0000 to 0x010B_FFFF
0x010C_0000 to 0x010F_FFFF
0x0110_0000 to 0x0113_FFFF
0x0114_0000 to 0x0117_FFFF
—
—
—
—
—
—
0x0040_0000 to 0x0040_1FFF
0x0040_8000 to 0x0040_BFFF
