RM0400
48.4.45

Frames transmitted with multiple collisions (IEEE_T_MCOL)

Offset: 254h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 734. Frames transmitted with multiple collisions (IEEE_T_MCOL)
Field
IEEE_T_MCOL Frames transmitted with multiple collisions
48.4.46 Frames transmitted after deferral delay (IEEE_T_DEF)
Offset: 258h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 735. Frames transmitted after deferral delay (IEEE_T_DEF)
Field
IEEE_T_DEF Frames transmitted after deferral delay
48.4.47 Frames transmitted with late collision (IEEE_T_LCOL)
Offset: 25Ch
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 736. Frames transmitted with late collision (IEEE_T_LCOL)
Field
IEEE_T_LCOL Frames transmitted with late collision
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 744. IEEE_T_MCOL field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 745. IEEE_T_DEF field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 746. IEEE_T_LCOL field descriptions
DocID027809 Rev 4
Fast Ethernet Controller (FEC)
IEEE_T_MCOL
Description
IEEE_T_DEF
Description
IEEE_T_LCOL
Description
Access: Read-only
Access: Read-only
Access: Read-only
1327/2058
