RM0400
See Figure 225 for details.

Table 260. Auxiliary Clock 8 Select Control Register (CGM_AC8_SC) field descriptions

Field
0–3 Reserved
Auxiliary Clock 8 Source Selection Control — This value selects the current source for auxiliary clock
8.
0000 reserved
0001 XOSC
0010 PLL0 PHI
0011 reserved
0100 reserved
0101 reserved
4–7
0110 reserved
0111 reserved
SELCTL
1000 reserved
1001 reserved
1010 reserved
1011 reserved
1100 reserved
1101 reserved
1110 reserved
1111 reserved
8–31 Reserved
24.3.1.29 Auxiliary Clock 8 Select Status Register (CGM_AC8_SS)
Address 0x0904
0 1 2
R 0 0 0
W
Reset 0 0 0
16 17 18
R 0 0 0
W
Reset 0 0 0
Figure 209. Auxiliary Clock 8 Select Status Register (CGM_AC8_SS)
This register provides the current auxiliary clock 8 source selection.
3 4 5 6
0 SELSTAT
0 0 0 0
19 20 21 22
0 0 0 0
0 0 0 0
DocID027809 Rev 4
Clock Generation Module (MC_CGM)
Description
Access: User read, Supervisor read, Test read
7 8 9 10
0 0 0
1 0 0 0
23 24 25 26
0 0 0 0
0 0 0 0
11 12 13 14
0 0 0 0
0 0 0 0
27 28 29 30
0 0 0 0
0 0 0 0
521/2058
15
0
0
31
0
0
