STMicroelectronics SPC572L series Reference Manual page 1377

RM0400
Field
Number of Data Nibbles supported in Channel 11
13:15
NIBBCH11 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
16 Reserved for future use. Reads returns zeros.
Number of Data Nibbles supported in Channel 12
17:19
NIBBCH12 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
20 Reserved for future use. Reads returns zeros.
Number of Data Nibbles supported in Channel 13
21:23
NIBBCH13 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
24 Reserved for future use. Reads returns zeros.
Number of Data Nibbles supported in Channel 14
25:27
NIBBCH14 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
28 Reserved for future use. Reads returns zeros.
Number of Data Nibbles supported in Channel 15
29:31
NIBBCH15 0 and 7 – Invalid value. Must not be used
1 to 6 – Number of data nibbles to be supported by respective channel
49.3.2.8 Fast Message DMA Control Register (FDMA_CTRL)
Note: The following register figure and table shows the maximum possible configuration but the
exact number of valid register bits are dependent on supported SENT channels on the
device. Please see Device Configuration chapter for number of support SENT channels.
Reads of bits beyond the supported number of channels should be ignored and writes to
these bits are unadvisable and may cause unexpected behavior.
