STMicroelectronics SPC572L series Reference Manual page 891

RM0400
Table 464. GTMDI_TOM_WPC1 field descriptions(Continued)
Field
TOM channel selection 1. Selects which channel within a selected TOM sub-module generates
watchpoints.
0000 TOM CH0
0001 TOM CH1
0010 TOM CH2
0011 TOM CH3
0100 TOM CH4
0101 TOM CH5
19–16
0110 TOM CH6
CHSEL1 0111 TOM CH7
1000 TOM CH8
1001 TOM CH9
1010 TOM CH10
1011 TOM CH11
1100 TOM CH12
1101 TOM CH13
1110 TOM CH14
1111 TOM CH15
TOM Channel Slope Selection 2. The TSS2 field selects the slope for the TOM selected channel.
00 Any transition (both)
13–12
01 Transition from 0 to 1 (positive slope)
TSS2
10 Transition from 1 to zero (negative slope)
11 Reserved
TOM sub-module Source Selection 2. Selects which TOM sub-module is the source for watchpoint
generation.
000 TOM0
001 TOM1
10–8
010 Reserved
SSEL2 011 Reserved
100 Reserved
101 Reserved
110 Reserved
111 Reserved
Halt Enable 2. The HEN1 Halt Enable 2 bit controls if the selected TOM Channel is used to halt the
GTM module. If this bit is set and an event occurs on the selected TOM Channel filter output, a Halt
7
signal is generated to the GTM which enters debug state.
HEN2
0 Disables Halt GTM
1 Enables Halt GTM
Description
DocID027809 Rev 4
GTM Development Interface (GTMDI)
891/2058
