Fast Ethernet Controller (FEC)
48.4.24

Count of frames not counted correctly (RMON_T_DROP)

Offset: 200h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 713. Count of frames not counted correctly (RMON_T_DROP)
Field
RMON_T_DROP Count of frames not counted correctly
48.4.25 RMON Tx packet count (RMON_T_PACKETS)
Offset: 204h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Field
RMON_T_PACKETS RMON Tx packet count
48.4.26 RMON Tx broadcast packets (RMON_T_BC_PKT)
Offset: 208h
0 1 2 3
R
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 715. RMON Tx broadcast packets (RMON_T_BC_PKT)
Field
RMON_T_BC_PKT
1320/2058
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 723. RMON_T_DROP field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Figure 714. RMON Tx packet count (RMON_T_PACKETS)
Table 724. RMON_T_PACKETS field descriptions
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Table 725. RMON_T_PACKETS field descriptions
RMON Tx broadcast packets
DocID027809 Rev 4
RMON_T_DROP
Description
RMON_T_PACKETS
Description
RMON_T_BC_PKT
Description
RM0400
Access: Read-only
Access: Read-only
Access: Read-only
