RM0400
Field
Error Passive
26
0 The M_CAN is in the Error_Active state. It normally takes part in bus communication and sends
an active error flag when an error has been detected
EP
1 The M_CAN is in the Error_Passive state
Activity
Monitors the module's CAN communication state.
27:28
00 Synchronizing – node is synchronizing on CAN communication
ACT
01 Idle—node is neither receiver nor transmitter
10 Receiver—node is operating as receiver
11 Transmitter—node is operating as transmitter
Last Error Code
The LEC indicates the type of the last error to occur on the CAN bus. This field will be cleared to
'0'
when a message has been transferred (reception or transmission) without error.
000 No Error: No error occurred since LEC has been reset by successful reception or
001 Stuff Error: More than 5 equal bits in a sequence have occurred in a part of a received
010 Form Error: A fixed format part of a received frame has the wrong format.
011 AckError: The message transmitted by the M_CAN was not acknowledged by another node.
100 Bit1Error: During the transmission of a message (with the exception of the arbitration field),
29:31
LEC
101 Bit0Error: During the transmission of a message (or acknowledge bit, or active error flag, or
110 CRCError: The CRC check sum of a received message was incorrect. The CRC of an
111 NoChange: Any read access to the Protocol Status Register re-initializes the LEC to '7'.
Note: When a frame in CAN FD format has reached the data phase with BRS flag set, the next
CAN event (error or valid frame) will be shown in FLEC instead of LEC. An error in a fixed
stuff bit of a CAN FD CRC sequence will be shown as a Form Error, not Stuff Error
Note: The Bus_Off recovery sequence (see CAN Specification Rev. 2.0 or ISO11898-1) cannot be
shortened by setting or resetting CCCR[INIT.] If the device goes Bus_Off, it will set
CCCR[INIT] of its own accord, stopping all bus activities. Once CCCR[INIT] has been
cleared by the CPU, the device will then wait for 129 occurrences of Bus Idle (129
consecutive recessive bits) before resuming normal operation. At the end of the Bus_Off
recovery sequence, the Error Management Counters will be reset. During the waiting time
after the resetting of CCCR[INIT], each time a sequence of 11 recessive bits has been
monitored, a Bit 0 Error code is written to PSR[LEC], enabling the CPU to readily check up
whether the CAN bus is stuck at dominant or continuously disturbed and to monitor the
Bus_Off recovery sequence. ECR[REC] is used to count these sequences.
Table 537. PSR descriptions(Continued)
transmission.
message where this is not allowed.
the device wanted to send a recessive level (bit of logical value '1'), but the monitored bus
value was dominant.
overload flag), the device wanted to send a dominant level (data or identifier bit logical value
'0'), but the monitored bus value was recessive. During Bus_Off recovery this status is set
each time a sequence of11 recessive bits has been monitored. This enables the CPU to
monitor the proceeding of the Bus_Off recovery sequence (indicating the bus is not stuck at
dominant or continuously disturbed).
incoming message does not match with the CRC calculated from the received data.
When the LEC shows the value '7', no CAN bus event was detected since the last CPU read
access to the Protocol Status Register.
DocID027809 Rev 4
Description
CAN Subsystem
×
11
1017/2058
1091
