Table 460. Gtmdi_Dc Field Descriptions - STMicroelectronics SPC572L series Reference Manual

GTM Development Interface (GTMDI)
Field
Global Debug Enable. This control bit disables all debug features of the GTMDI module including
ability to put GTM IP in Halt state, modify EVTO output, send messages to the DATA bus and set
triggers to the SPU module. Before changing the GTMDI configuration it is recommended to clear
31
GDE bit to prevent spurious behavior of the module outputs. See
GDE
debug enable logic.
0 GTMDI Global debug is disabled
1 GTMDI Global debug is enabled
EVTO0 Output Selection. This signal is dedicated to sel 1 which is the selection 1 from the
indicated GTM modules. See the control registers for each module for a description of this
selection. For TIM, TOM and ATOM selections the input filtered signal or output channel signal are
used instead of the triggers.
0000 No event on output EVTO0 remains at one
0001 Halt Indication, If EVTO0 is zero indicates that GTM is halted
0010 TIM, Map EVTO0 from TIM channel filter output using ssel 1 selection control
0011 TOM, Map EVTO0 from TOM channel output using ssel1 selection control
0100 ATOM, Map EVTO0 from ATOM channel output using ssel 1 selection control
27–24
0101 SPEA, Map EVTO0 from SPEA, controlled by TSS1 described in
EOS0 0110 SPEB, Map EVTO0 from SPEB, controlled by TSS1 described in
0111 ARU CH0, Map EVTO0 from ARU CH0l
1000 DPLL, Map EVTO0 from DPLL according to TSEL1 in
1001 MCSA, Map EVTO0 from MCSA MCSA_sel selection control
1010 MCSB, Map EVTO0 from MCSB MCSB_sel selection control
1011 TBU0 Watchpoint 1, Watchpoint controlled by TSS1 in GTMDI_TBU0_WPC1 register
1100 TBU1 watchpoint 1, Watchpoint controlled by TSS1 in GTMDI_TBU1_WPC1 register
1101 TBU2 watchpoint 1, Watchpoint controlled by TSS1 in GTMDI_TBU2_WPC1 register
1110 Reserved
1111 Reserved
EVTO1 Output Selection. This signal is dedicated to sel 2 which is the selection 2 from the
indicated GTM modules. See the control registers for each module for a description of this
selection. For TIM, TOM and ATOM selections the input filtered signal or output channel signal are
used instead of the triggers.
0000 No event on output EVTO1 remains at one
0001 Halt Indication, If EVTO1 is zero indicates that GTM is halted
0010 TIM, Map EVTO1 from TIM channel filter output using ssel 1 selection control
0011 TOM, Map EVTO1 from TOM channel output using ssel1 selection control
0100 ATOM, Map EVTO1 from ATOM channel output using ssel 1 selection control
19–16
0101 SPEA, Map EVTO1 from SPEA, controlled by TSS2 described in
EOS1 0110 SPEB, Map EVTO1 from SPEB, controlled by TSS2 described in
0111 ARU CH1, Map EVTO1 from ARU CH1
1000 DPLL, Map EVTO1 from DPLL according to TSEL2A/B in
1001 MCSA, Map EVTO1 from MCSA MCSA_sel selection control
1010 MCSB, Map EVTO1 from MCSB MCSB_sel selection control
1011 TBU0 Watchpoint 2, Watchpoint controlled by TSS2 in GTMDI_TBU0_WPC1 register
1100 TBU1 watchpoint 2, Watchpoint controlled by TSS2 in GTMDI_TBU1_WPC1 register
1101 TBU2 watchpoint 2, Watchpoint controlled by TSS2 in GTMDI_TBU2_WPC1 register
1110 Reserved
1111 Reserved
