RM0400
45.7.3

Register Write transfer

Register Write transfer can be of two types:
•
Normal Write transfer – channels 0, 1, 2 and 3
•
Streaming Data transfer – channel 2 only
A Register Write transfer can be done through Normal Write transfer - channels 0, 1, 2 and
3 (see <Cross Refs>Section 45.7.3.1, Normal write transfer) as shown in
Figure 552. Register write transfer (showing LFAST frame encapsulation)
Sync
16 bits
45.7.3.1 Normal write transfer
A normal write transfer contains header, address, data (32-bit) and 16-bit CRC as shown in
Figure 553.
Header
Header
8 bits 16 bits
DocID027809 Rev 4
Serial Interprocessor Interface (SIPI)
Address Data
64 bits
96 bits
SIPI Frame
LFAST Frame
Figure 552.
Bit Stream Direction
CRC16 End
16 bits 1 bit
