Table 179. Dma_Hrsl Field Descriptions - STMicroelectronics SPC572L series Reference Manual

Enhanced Direct Memory Access (eDMA)
Field
Hardware request status channel 15
16
0 A hardware service request for the corresponding channel is not present
HRS15
1 A hardware service request for the corresponding channel is present
Hardware request status channel 14
17
0 A hardware service request for the corresponding channel is not present
HRS14
1 A hardware service request for the corresponding channel is present
Hardware request status channel 13
18
0 A hardware service request for the corresponding channel is not present
HRS13
1 A hardware service request for the corresponding channel is present
Hardware request status channel 12
19
0 A hardware service request for the corresponding channel is not present
HRS12
1 A hardware service request for the corresponding channel is present
Hardware request status channel 11
20
0 A hardware service request for the corresponding channel is not present
HRS11
1 A hardware service request for the corresponding channel is present
Hardware request status channel 10
21
0 A hardware service request for the corresponding channel is not present
HRS10
1 A hardware service request for the corresponding channel is present
Hardware request status channel 9
22
0 A hardware service request for the corresponding channel is not present
HRS9
1 A hardware service request for the corresponding channel is present
Hardware request status channel 8
23
0 A hardware service request for the corresponding channel is not present
HRS8
1 A hardware service request for the corresponding channel is present
Hardware request status channel 7
24
0 A hardware service request for the corresponding channel is not present
HRS7
1 A hardware service request for the corresponding channel is present
Hardware request status channel 6
25
0 A hardware service request for the corresponding channel is not present
HRS6
1 A hardware service request for the corresponding channel is present
Hardware request status channel 5
26
0 A hardware service request for the corresponding channel is not present
HRS5
1 A hardware service request for the corresponding channel is present
Hardware request status channel 4
27
0 A hardware service request for the corresponding channel is not present
HRS4
1 A hardware service request for the corresponding channel is present
Hardware request status channel 3
28
0 A hardware service request for the corresponding channel is not present
HRS3
1 A hardware service request for the corresponding channel is present
Hardware request status channel 2
29
0 A hardware service request for the corresponding channel is not present
HRS2
1 A hardware service request for the corresponding channel is present
414/2058

Table 179. DMA_HRSL field descriptions

DocID027809 Rev 4
Description
RM0400
