RM0400
IRQ # Offset
SAR ADC0 combined interrupt:
– NEOC (end of normal conversion of each
channel)
– NECH (end of normal chain)
528 1840h – JEOC (end of injected conversion of each
channel)
– JECH (end of injected chain)
– Add WDGxL (watchDog Low int)
– WDGxH (watchDog High int)
SAR ADC4 combined interrupt:
– NEOC (end of normal conversion of each
channel)
– NECH (end of normal chain)
532 1850h – JEOC (end of injected conversion of each
channel)
– JECH (end of injected chain)
– Add WDGxL (watchDog Low int)
– WDGxH (watchDog High int)
SAR_ADCB combined interrupt:
– NEOC (end of normal conversion of each
channel)
– NECH (end of normal chain)
543 187Ch – JEOC (end of injected conversion of each
channel)
– JECH (end of injected chain)
– Add WDGxL (watchDog Low int)
– WDGxH (watchDog High int)
SD ADC3 combined interrupt:
– Data FIFO empty
547 188Ch
– Data FIFO full
– Data FIFO overrun
SENT_0 Fast messages combined interrupt:
558 18B8h
OR of all enabled Fast message Ready flags
SENT_0 Slow messages combined interrupt:
559 18BCh
OR of all enabled Slow message Ready flags
Table 22. Interrupt sources(Continued)
Source description
DocID027809 Rev 4
Source name
SARADC_0_ICIPR0[EOC_CH[7]] |
SARADC_0_ICIPR0[EOC_CH[6]] |
SARADC_0_ICIPR0[EOC_CH[5]] |
SARADC_0_ICIPR0[EOC_CH[4]] I
SARADC_0_ICIPR0[EOC_CH[8]] I
SARADC_0_ICIPR0[EOC_CH[0]] I
SARADC_0_ICIPR0[EOC_CH[1]] I
SARADC_0_ICIPR0[EOC_CH[2]] I
SARADC_0_ICIPR0[EOC_CH[3]]
SARADC_4_ICIPR0[EOC_CH[61]]|
.......
SARADC_4_ICIPR0[EOC_CH[55]]|
SARADC_4_ICIPR0[EOC_CH[54]]|
SARADC_4_ICIPR0[EOC_CH[53]]|
SARADC_4_ICIPR0[EOC_CH[52]]
SARADC_B_ICIPR0[EOC_CH[31] |
SARADC_B_ICIPR0[EOC_CH[30] | ... |
SARADC_B_ICIPR0[EOC_CH[1] |
SARADC_B_ICIPR0[EOC_CH[0]] |
SARADC_B_ICIPR1[EOC_CH[61]] | ... |
SARADC_B_ICIPR1[EOC_CH[56]] |
SARADC_B_ICIPR1[EOC_CH[53]] | ... |
SARADC_B_ICIPR1[EOC_CH[0]]
SDADC_3_SFR[DFEF] |
SDADC_3_SFR[DFORF] |
SDADC_3_SFR[DFFF]
SENT_0_FMSG_RDY[0] |
SENT_0_FMSG_RDY[1] |
SENT_0_FMSG_RDY[2] |
SENT_0_FMSG_RDY[3]
SENT_0_SMSG_RDY[0] |
SENT_0_SMSG_RDY[1] |
SENT_0_SMSG_RDY[2] |
SENT_0_SMSG_RDY[3]
Device configuration
