STMicroelectronics SPC572L series Reference Manual page 132

Device configuration
IRQ # Offset
LINFlexD_1 Transmission combined interrupt:
– Header Received
381 15F4h
– Data Transmitted
– Data Buffer Empty
LINFlexD_1 Error combined interrupt:
– Stuck at zero
– Output Compare
– Bit Error
382 15F8h – Checksum Error
– Header Error
– Frame Error
– Buffer Overrun
– UART Timeout Error
LINFlexD_14 Reception combined interrupt
– Header Received
– Data Reception complete
432 16C0h
– Data Buffer Full
– Wakeup
– LIN State (Sync Del, Sync Field, Identifier
Field or Checksum Field)
LINFlexD_14 Transmission combined interrupt:
– Header Received
433 16C4h
– Data Transmitted
– Data Buffer Empty
LINFlexD_14 Error combined interrupt:
– Stuck at zero
– Output Compare
– Bit Error
434 16C8h – Checksum Error
– Header Error
– Frame Error
– Buffer Overrun
– UART Timeout Error
Power Management Controller Supply Gauge
477 1774h Low Voltage Detect and High Voltage Detect
Interrupts
Power Management Controller Temperature
478 1778h
Sensor interrupts
480 1780h Loss-of-lock interrupt request for PLL0
484 1790h PLL_0_1
132/2058
Table 22. Interrupt sources(Continued)
Source description
DocID027809 Rev 4
Source name
LINFlexD_1_LINIER[HRIE] |
LINFlexD_1_LINIER[DTIE] |
LINFlexD_1_LINIER[DBEIE]
LINFlexD_1_LINIER[SZIE] |
LINFlexD_1_LINIER[OCIE] |
LINFlexD_1_LINIER[BEIE] |
LINFlexD_1_LINIER[CEIE] |
LINFlexD_1_LINIER[HEIE] |
LINFlexD_1_LINIER[FEIE] |
LINFlexD_1_LINIER[BOIE] |
LINFlexD_1_LINIER[TOIE]
LINFlexD_14_LINIER[HRIE] |
LINFlexD_14_LINIER[DRIE] |
LINFlexD_14_LINIER[DBFIE] |
LINFlexD_14_LINIER[WUIE] |
LINFlexD_14_LINIER[LSIE]
LINFlexD_14_LINIER[HRIE] |
LINFlexD_14_LINIER[DTIE] |
LINFlexD_14_LINIER[DBEIE]
LINFlexD_14_LINIER[SZIE] |
LINFlexD_14_LINIER[OCIE] |
LINFlexD_14_LINIER[BEIE] |
LINFlexD_14_LINIER[CEIE] |
LINFlexD_14_LINIER[HEIE] |
LINFlexD_14_LINIER[FEIE] |
LINFlexD_14_LINIER[BOIE] |
LINFlexD_14_LINIER[TOIE]
GR_S[VD15] | GR_S[VD14] | GR_S[VD13] |
GR_S[VD12] | GR_S[VD10] | GR_S[VD9] |
GR_S[VD7] | GR_S[VD4] | GR_S[VD3]
EPR_TD[TEMP_3] | EPR_TD[TEMP_2] |
EPR_TD[TEMP_0]
PLL0SR[LOLF]
PLL0SR[EXTPDF]
RM0400
