System Memory Protection Unit (SMPU)
Absolute
address (hex)
FC01_046C SMPU0_RGD6_WORD3
FC01_0470 SMPU0_RGD7_WORD0
FC01_0474 SMPU0_RGD7_WORD1
FC01_0478 SMPU0_RGD7_WORD2_FMT0
FC01_0478 SMPU0_RGD7_WORD2_FMT1
FC01_047C SMPU0_RGD7_WORD3
FC01_0480 SMPU0_RGD8_WORD0
FC01_0484 SMPU0_RGD8_WORD1
FC01_0488 SMPU0_RGD8_WORD2_FMT0
FC01_0488 SMPU0_RGD8_WORD2_FMT1
FC01_048C SMPU0_RGD8_WORD3
FC01_0490 SMPU0_RGD9_WORD0
FC01_0494 SMPU0_RGD9_WORD1
FC01_0498 SMPU0_RGD9_WORD2_FMT0
FC01_0498 SMPU0_RGD9_WORD2_FMT1
FC01_049C SMPU0_RGD9_WORD3
FC01_04A0 SMPU0_RGD10_WORD0
FC01_04A4 SMPU0_RGD10_WORD1
FC01_04A8 SMPU0_RGD10_WORD2_FMT0
FC01_04A8 SMPU0_RGD10_WORD2_FMT1
FC01_04AC SMPU0_RGD10_WORD3
FC01_04B0 SMPU0_RGD11_WORD0
FC01_04B4 SMPU0_RGD11_WORD1
FC01_04B8 SMPU0_RGD11_WORD2_FMT0
FC01_04B8 SMPU0_RGD11_WORD2_FMT1
FC01_04BC SMPU0_RGD11_WORD3
1. SMPU0_RGDn_WORD2_FMT0 implemented when SMPU0_RGDn_WORD3[FMT] = 0. SMPU0_RGDn_WORD2_FMT1
implemented when SMPU0_RGDn_WORD3[FMT] = 1.
330/2058
Table 141. SMPUx memory map(Continued)
Register name
1
1
1
1
1
1
1
1
1
1
DocID027809 Rev 4
Width
Access Reset value
(in bits)
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
RM0400
Section
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
