Analog modules

This section highlights the following analog modules that are implemented on SPC572Lx:
Module or Subsystem
Temperature sensor
ADC subsystem
Sigma-Delta Analog-to-
Digital Converters
(SDADCs)
Successive Approximation
Register Analog-to-Digital
Converters (SARADCs)
6.4.6

Temperature sensor configuration

The temperature sensor is used to measure the temperature of the SPC572Lx device. In
general, the temperature sensor generates an analog voltage that is linearly proportional to
temperature.
During production testing of the device, the output of the temperature sensor is sampled by
SARB input channel 120 of the onboard ADC module at a predefined high temperature and
also at a predefined low temperature. These two temperature sensor readings are used to
calculate two constants, TSCA and TSCB, according to the formulas in the
Temperature
Once calculated, the values for TSCA and TSCB are programmed during production test
into the UTEST Flash Memory.
The temperature sensor bandgap voltage used in the temperature calculation is sampled by
SARB input channel 121 of the onboard ADC module.
Software must perform the following steps in order to calculate device temperature:
1. Measure the bandgap voltage, V
ADC module.
2. Calculate V
3. Measure the temperature sensor output voltage, V
120 of the onboard ADC module.
4. Calculate T
Sensor.
5. Retrieve parameters TSCA and TSCB from flash memory.
6. Calculate temperature (T) according to the formula in
Sensor.
6.4.7

Analog-to-Digital Converters (ADC) configuration

See Chapter 34: Analog-to-digital converter (ADC) configuration
subsystem, including a block diagram and a summary of analog input pin multiplexing. The
chapter also provides configuration details for the SARADCs and SDADCs.
