13.2.2.11.2 Multiplexed Signal Configuration Registers for Multiplexed Input Selection
(SIUL2_MSCR_MUX_512–SIUL2_MSCR_MUX_1023)
The multiplexed input selection MSCR definition is given in
select the input source for IP blocks on the device that have inputs from multiple sources,
both other IP blocks and I/O pins. It is possible to configure the pad to be in input without
having to connect it externally. This is possible, either by enabling internal pull-up/pull-down
or disabling the input buffer (but in this case data is seen as 0 internally).
Address: 0X0A40–0x123C
0 1
R 0 0
W
Reset 0 0
16 17
R
INV
W
Reset 0 0
Figure 66. Multiplexed Signal Configuration Registers for Multiplexed Input Selection
Table 126. SIUL2_MSCR_MUX_512–SIUL2_MSCR_MUX_1023 field description
Field
0–15 Reserved
Invert—Inverts the signal selected by SSS before transmitting it to the associated destination
16 (chip pin or module port).
INV 0 Don't invert
1 Invert
