Generic Pins - STMicroelectronics SPC572L series Reference Manual

Signal description
Functional Port
block pin
PD[3]
PD[2]
DSPI 4
Microsecond
Bus
PD[1]
PD[0]
1. DRCLK and TCK/DRCLK usage for SIPI LFAST is described in the SPC572Lx reference manual, refer to SIPI LFAST
chapter.
4.3.5

Generic pins

The Signal Description table contains the port definition, multiplexing, direction, pad type,
and package pin numbers for each I/O pin on the device.Multi-function pins are
programmable via their respective Multiplexed Signal Configuration Register (MSCR)
values.
Note: The SPC572Lx "I/O signal description and input multiplexing table is contained in a
Microsoft Excel
the left side of the PDF window, and click it. Double-click on the excel file to open it and
select the I/O Signal Description Table tab.
• Multi-function pins are programmable via their respective Multiplexed Signal
Configuration Register (MSCR) Source Signal Select (SSS) values. The SSS value selects
which source signal is connected to the associated destination.
• For additional information, refer to
108/2058
Table 6. LVDSM pin descriptions(Continued)
Signal Signal description
DSPI 4 Microsecond Bus Serial
SCK_N
Clock, LVDS Negative Terminal
DSPI 4 Microsecond Bus Serial
SCK_P
Clock, LVDS Positive Terminal
DSPI 4 Microsecond Bus Serial
SOUT_N
Data, LVDS Negative Terminal
DSPI 4 Microsecond Bus Serial
SOUT_P
Data, LVDS Positive Terminal
®
workbook file attached to this document. Locate the paperclip symbol on
DocID027809 Rev 4
Direction
O
O
O
O
Chapter 13: System Integration Unit Lite2
RM0400
Package pin number
eTQFP80 eTQFP100
69 87
70 88
71 89
72 90
(SIUL2).
