Table 93. EFPU Status and Control Register field descriptions(Continued)
Bits Name
25
FINXE
(57)
26
FINVE
(58)
27
FDBZE
(59)
28
FUNFE
(60)
29
FOVFE
(61)
30:31
FRMC
(62:63)
12.6

Exceptions

Interrupts implemented in e200z215An3 and the exception conditions that cause them are
listed in Table
266/2058
Embedded Floating-point Inexact Exception Enable
If the exception is enabled, a Floating-point Round exception is taken if the result of a
Floating-point instruction does not result in overflow or underflow, and the result is inexact
(FG | FX = 1), or if the result of a Floating-point instruction does result in overflow
(FOVF = 1) but Floating-point Overflow exceptions are disabled (FOVFE = 0), or if the
result of a Floating-point instruction results in underflow (FUNF = 1 or FUNFH = 1) but
Floating-point Underflow exceptions are disabled (FUNFE = 0), and no Floating-point Data
exception occurs.
0 Exception disabled
1 Exception enabled
Embedded Floating-point Invalid Operation / Input Error Exception Enable
If the exception is enabled, a Floating-point Data exception is taken if the FINV bit is set by
a floating-point instruction.
0 Exception disabled
1 Exception enabled
Embedded Floating-point Divide by Zero Exception Enable
If the exception is enabled, a Floating-point Data exception is taken if the FDBZ bit is set
by a floating-point instruction.
0 Exception disabled
1 Exception enabled
Embedded Floating-point Underflow Exception Enable
If the exception is enabled, a Floating-point Data exception is taken if the FUNF bit is set
by a floating-point instruction.
0 Exception disabled
1 Exception enabled
Embedded Floating-point Overflow Exception Enable
If the exception is enabled, a Floating-point Data exception is taken if the FOVF bit is set
by a floating-point instruction.
0 Exception disabled
1 Exception enabled
Embedded Floating-point Rounding Mode Control
00 Round to Nearest
01 Round toward Zero
10 Round toward +Infinity
11 Round toward –Infinity
