IRQ # Offset
SENT_0 Channel 1 combined Error interrupt:
– Successive calibration check resynchronized
error
– Calibration variation 20 – 25%
– Slow message overflow
– Fast message overflow
569 18E4h – Number of negative edges error
– Checksum error in fast message
– Checksum error in slow message
– Nibble data value error
– Calibration pulse length error
– Calibration pulse length ratio to message
length error
570 18E8h SENT_0 Channel 2 Fast message interrupt
571 18ECh SENT_0 Channel 2 Slow message interrupt
SENT_0 Channel 2 combined Error interrupt:
– Successive calibration check resynchronized
error
– Calibration variation 20 – 25%
– Slow message overflow
– Fast message overflow
572 18F0h – Number of negative edges error
– Checksum error in fast message
– Checksum error in slow message
– Nibble data value error
– Calibration pulse length error
– Calibration pulse length ratio to message
length error
573 18F4h SENT_0 Channel 3 Fast message interrupt
574 18F8h SENT_0 Channel 3 Slow message interrupt
SENT_0 Channel 3 combined Error interrupt:
– Successive calibration check resynchronized
error
– Calibration variation 20 – 25%
– Slow message overflow
– Fast message overflow
575 18FCh – Number of negative edges error
– Checksum error in fast message
– Checksum error in slow message
– Nibble data value error
– Calibration pulse length error
– Calibration pulse length ratio to message
length error
Table 22. Interrupt sources(Continued)
Source description
DocID027809 Rev 4
Source name
SENT_0_CH1_STATUS[4:7] |
SENT_0_CH1_STATUS[9:15]
SENT_0_FMSG_RDY[2]
SENT_0_SMSG_RDY[2]
SENT_2_CH2_STATUS[4:7] |
SENT_2_CH2_STATUS[9:15]
SENT_0_FMSG_RDY[3]
SENT_0_SMSG_RDY[3]
SENT_0_CH3_STATUS[4:7] |
SENT_0_CH3_STATUS[9:15]
