STMicroelectronics SPC572L series Reference Manual page 329

RM0400
Absolute
address (hex)
FC01_0400 SMPU0_RGD0_WORD0
FC01_0404 SMPU0_RGD0_WORD1
FC01_0408 SMPU0_RGD0_WORD2_FMT0
FC01_0408 SMPU0_RGD0_WORD2_FMT1
FC01_040C SMPU0_RGD0_WORD3
FC01_0410 SMPU0_RGD1_WORD0
FC01_0414 SMPU0_RGD1_WORD1
FC01_0418 SMPU0_RGD1_WORD2_FMT0
FC01_0418 SMPU0_RGD1_WORD2_FMT1
FC01_041C SMPU0_RGD1_WORD3
FC01_0420 SMPU0_RGD2_WORD0
FC01_0424 SMPU0_RGD2_WORD1
FC01_0428 SMPU0_RGD2_WORD2_FMT0
FC01_0428 SMPU0_RGD2_WORD2_FMT1
FC01_042C SMPU0_RGD2_WORD3
FC01_0430 SMPU0_RGD3_WORD0
FC01_0434 SMPU0_RGD3_WORD1
FC01_0438 SMPU0_RGD3_WORD2_FMT0
FC01_0438 SMPU0_RGD3_WORD2_FMT1
FC01_043C SMPU0_RGD3_WORD3
FC01_0440 SMPU0_RGD4_WORD0
FC01_0444 SMPU0_RGD4_WORD1
FC01_0448 SMPU0_RGD4_WORD2_FMT0
FC01_0448 SMPU0_RGD4_WORD2_FMT1
FC01_044C SMPU0_RGD4_WORD3
FC01_0450 SMPU0_RGD5_WORD0
FC01_0454 SMPU0_RGD5_WORD1
FC01_0458 SMPU0_RGD5_WORD2_FMT0
FC01_0458 SMPU0_RGD5_WORD2_FMT1
FC01_045C SMPU0_RGD5_WORD3
FC01_0460 SMPU0_RGD6_WORD0
FC01_0464 SMPU0_RGD6_WORD1
FC01_0468 SMPU0_RGD6_WORD2_FMT0
FC01_0468 SMPU0_RGD6_WORD2_FMT1
Table 141. SMPUx memory map(Continued)
Register name
(1)
1
1
1
1
1
1
1
1
1
1
1
1
1
DocID027809 Rev 4
System Memory Protection Unit (SMPU)
Width
Access Reset value
(in bits)
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
32 R/W 0000_0000h
Section
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
Section 16.4.2.9
Section 16.4.2.5
Section 16.4.2.6
Section 16.4.2.7
Section 16.4.2.8
329/2058
