STMicroelectronics SPC572L series Reference Manual page 140

Device configuration
IRQ # Offset
GTM TIM0 Channel 1 shared interrupt:
– New measurement value detected by SMU for
channel (NEWVALx_IRQ)
– ECNT counter overflow of channel
(ECNTOFLx_IRQ)
750 1BB8h
– SMU counter overflow (CNTOFLx_IRQ)
– GPRz data overflow (GPRzOFLx_IRQ)
– Timeout of input signal (TOx_IRQ)
– Glitch detected on input (GLITCHDETx_IRQ)
GTM TIM0 Channel 2 shared interrupt:
– New measurement value detected by SMU for
channel (NEWVALx_IRQ)
– ECNT counter overflow of channel
(ECNTOFLx_IRQ)
751 1BBCh
– SMU counter overflow (CNTOFLx_IRQ)
– GPRz data overflow (GPRzOFLx_IRQ)
– Timeout of input signal (TOx_IRQ)
– Glitch detected on input (GLITCHDETx_IRQ)
GTM TIM0 Channel 3 shared interrupt:
– New measurement value detected by SMU for
channel (NEWVALx_IRQ)
– ECNT counter overflow of channel
(ECNTOFLx_IRQ)
752 1BC0h
– SMU counter overflow (CNTOFLx_IRQ)
– GPRz data overflow (GPRzOFLx_IRQ)
– Timeout of input signal (TOx_IRQ)
– Glitch detected on input (GLITCHDETx_IRQ)
GTM TIM0 Channel 4 shared interrupt:
– New measurement value detected by SMU for
channel (NEWVALx_IRQ)
– ECNT counter overflow of channel
(ECNTOFLx_IRQ)
753 1BC4h
– SMU counter overflow (CNTOFLx_IRQ)
– GPRz data overflow (GPRzOFLx_IRQ)
– Timeout of input signal (TOx_IRQ)
– Glitch detected on input (GLITCHDETx_IRQ)
GTM TIM0 Channel 5 shared interrupt:
– New measurement value detected by SMU for
channel (NEWVALx_IRQ)
– ECNT counter overflow of channel
(ECNTOFLx_IRQ)
754 1BC8h
– SMU counter overflow (CNTOFLx_IRQ)
– GPRz data overflow (GPRzOFLx_IRQ)
– Timeout of input signal (TOx_IRQ)
– Glitch detected on input (GLITCHDETx_IRQ)
140/2058
Table 22. Interrupt sources(Continued)
Source description
DocID027809 Rev 4
Source name
GTM_ICM_IRQG_2[TIM0_CH1_IRQ]
GTM_ICM_IRQG_2[TIM0_CH2_IRQ]
GTM_ICM_IRQG_2[TIM0_CH3_IRQ]
GTM_ICM_IRQG_2[TIM0_CH4_IRQ]
GTM_ICM_IRQG_2[TIM0_CH5_IRQ]
RM0400
