RM0400
6.4.3

ECC Error Reporting Module

The Error Reporting Module (ERM) provides information and optional interrupt notification
on memory error events associated with ECC (Error Correction Code).
The ERM collects ECC events on memory accesses for local memory arrays, such as flash,
system RAM or peripheral RAMs.
Table 32
6.4.4

ECC Error Injection Module

The Error Injection Module (EIM) provides support for inducing single-bit and multi-bit
inversions on read data when accessing peripheral RAM.
Table 33
The Error Injection on the Flash memory can be handled by reading the ECC/EDC test
pattern available in the UTEST memory.
lists the memory assignment to the ERM channels on SPC572Lx.
Table 32. ERM memory assignment
ERM memory channel
Memory0
Memory1
Memory2
Memory3
Memory4
Memory5
Memory6
Memory7
lists the memory assignment to the EIM channels on SPC572Lx.
Table 33. EIM memory assignment
EIM channel
Memory0
Memory1
Memory2
Memory3
Memory4
Memory5
DocID027809 Rev 4
Assigned memory
System SRAM (read by crossbar slave port S1)
eDMA RAM
Fast Ethernet Controller MIB RAM
Fast Ethernet Controller FIFO RAM
FLASH (code flash, data flash, flash controller
RAM)
Overlay RAM (calibration RAM)
System SRAM (read by pFlash controller through
overlay backdoor)
M_CAN shared RAM
GTM RAM
Assigned memory
System SRAM
eDMA RAM
Fast Ethernet Controller MIB RAM
Fast Ethernet Controller FIFO RAM
Overlay RAM0
Overlay RAM1
Device configuration
