Device configuration
IRQ # Offset
690 1AC8h M_CAN_2 Line0 combined interrupt
691 1ACCh M_CAN_2 Line1 combined interrupt
706 1B08h GTM AEI Shared interrupt
707 1B0Ch GTM ARU New Data0 transferred interrupt
708 1B10h GTM ARU New Data1 transferred interrupt
709 1B14h GTM ARU access acknowledge interrupt
711 1B1Ch GTM compare shared module interrupt
712 1B20h GTM Sensor pattern evaluation 0 interrupt
713 1B24h GTM Sensor pattern evaluation 1 interrupt
GTM Parameter Storage Module 0 Channel 0
714 1B28h
interrupt
GTM Parameter Storage Module 0 Channel 1
715 1B2Ch
interrupt
GTM Parameter Storage Module 0 Channel 2
716 1B30h
interrupt
GTM Parameter Storage Module 0 Channel 3
717 1B34h
interrupt
GTM Parameter Storage Module 0 Channel 4
718 1B38h
interrupt
GTM Parameter Storage Module 0 Channel 5
719 1B3Ch
interrupt
GTM Parameter Storage Module 0 Channel 6
720 1B40h
interrupt
GTM Parameter Storage Module 0 Channel 7
721 1B44h
interrupt
722 1B48h DPLL_DCGI: DPLL direction change interrupt
723 1B4Ch DPLL_EDI: DPLL enable or disable interrupt
DPLL_TINI: DPLL TRIG. min. hold time (THMI)
724 1B50h
viol. detected
DPLL_TAXI: DPLL TRIG. max. hold time
725 1B54h
(THMA) viol. detected
DPLL_SISI: DPLL STATE inactive slope
726 1B58h
detected
DPLL_TISI: DPLL TRIGGER inactive slope
727 1B5Ch
detected
138/2058
Table 22. Interrupt sources(Continued)
Source description
DocID027809 Rev 4
Source name
(M_CAN_2_IR[0] & ~M_CAN_2_ILS[0])| ... |
(M_CAN_2_IR[11] & ~M_CAN_2_ILS[11]) |
(M_CAN_2_IR[13] & ~M_CAN_2_ILS[13]) | ... |
(M_CAN_2_IR[31] & ~M_CAN_2_ILS[31])
(M_CAN_2_IR[0] & M_CAN_2_ILS[0])| ... |
(M_CAN_2_IR[11] & M_CAN_2_ILS[11]) |
(M_CAN_2_IR[13] & M_CAN_2_ILS[13]) | ... |
(M_CAN2__IR[31] & M_CAN_2_ILS[31])
GTM_AEI_IRQ AEI
GTM_ARU_IRQ[0]
GTM_ARU_IRQ[1]
GTM_ARU_IRQ[2]
GTM_CMP_IRQ
GTM_SPE0_IRQ
GTM_SPE1_IRQ
GTM_PSM0_IRQ[0]
GTM_PSM0_IRQ[1]
GTM_PSM0_IRQ[2]
GTM_PSM0_IRQ[3]
GTM_PSM0_IRQ[4]
GTM_PSM0_IRQ[5]
GTM_PSM0_IRQ[6]
GTM_PSM0_IRQ[7]
GTM_DPLL_IRQ[0]
GTM_DPLL_IRQ[1]
GTM_DPLL_IRQ[2]
GTM_DPLL_IRQ[3]
GTM_DPLL_IRQ[4]
GTM_DPLL_IRQ[5]
RM0400
