Reset Generation Module (MC_RGM)

Table 859. 'Functional' Event Status (RGM_FES) register Field Descriptions

Field
0–5 Reserved
Flag for Flash fatal error reset
6
0 No Flash fatal error reset event has occurred since either the last clear or the last power-on
F_FLASH reset assertion.
1 A Flash fatal error reset event has occurred.
Flag for voltage out of range 'functional' reset
7
0 No voltage out of range 'functional' reset event has occurred since either the last clear or the
F_VOR_FUNC last power-on reset assertion
1 A voltage out of range 'functional' reset event has occurred
Flag for temperature sensor 'functional' reset
8
0 No temperature sensor 'functional' reset event has occurred since either the last clear or the
F_TSR_FUNC last power-on reset assertion
1 A temperature sensor 'functional' reset event has occurred
9–14 Reserved
Flag for PLL0 lock failure
15
0 No PLL0 lock failure event has occurred since either the last clear or the last power-on reset
F_PLL0 assertion.
1 A PLL0 lock failure event has occurred.
16–17 Reserved
Flag for system frequency out of range
18
0 No system frequency out of range event has occurred since either the last clear or the last
F_CMU_FHL0 power-on reset assertion.
1 A system frequency out of range event has occurred.
Flag for oscillator failure
19
0 No oscillator failure event has occurred since either the last clear or the last power-on reset
F_CMU_OLR assertion.
1 A oscillator failure event has occurred.
Flag for core debug reset
20
0 No core debug reset event has occurred since either the last clear or the last power-on reset
F_CORE assertion.
1 A core debug reset event has occurred.
Flag for JTAG 'functional' reset request
21
0 No JTAG 'functional' reset request event has occurred since either the last clear or the last
F_JTAG_FUNC power-on reset assertion.
1 A JTAG 'functional' reset request event has occurred.
Flag for Core Watchdog reset
22
0 No Core Watchdog reset event has occurred since either the last clear or the last power-on
F_CWD reset assertion.
1 A Core Watchdog reset event has occurred.
Flag for System Watchdog reset
23
0 No System Watchdog reset event has occurred since either the last clear or the last power-on
F_SWT reset assertion.
1 A System Watchdog reset event has occurred.
24–27 Reserved
